KB301 Vertical, Surface-Mounted Baby Changing Station

Part of Koala’s Signature Series, the KB301 vertical surface-mounted baby changing station delivers the commercial-grade durability, safety, and reliability that businesses and designers have trusted from Koala for decades. Designed for commercial restrooms where maximizing available wall space is essential, the vertical configuration is an ideal solution for restaurants, coffee shops, offices, and other facilities with smaller restroom footprints. Available in Beige, Gray, Black, and White Granite, it complements a wide range of restroom styles. The KB301 combines durable polypropylene construction, a concealed steel support frame, Microban® antimicrobial protection, and integrated hygiene features to provide an exceptional restroom experience for caregivers while making efficient use of available space.

Built for Commercial Environments
Constructed from durable, non-porous polypropylene, the KB301 is designed for busy commercial restrooms, providing a smooth, easy-to-clean surface. A concealed steel frame delivers exceptional strength and rigidity, supporting children up to 50 lbs. (22.7 kg). The unit has been tested to 150 lbs. (68 kg.) with minimal deflection and exceeds ASTM F2285 static load requirements, providing long-term performance in demanding environments. Four color options make it easy to coordinate with both traditional and contemporary restroom designs.

Designed for Better Restroom Experiences
Two integrated dispensers provide easy access to sanitary bed liners and Koala Diaper Pouch® diaper disposal bags, encouraging proper hygiene and waste containment. The non-porous changing surface is infused with Microban® antimicrobial protection, helping inhibit the growth of odor-causing bacteria and keeping the surface cleaner between cleanings for the life of the product. A concealed gas shock provides smooth, controlled opening and closing, which requires less than 5 lbs. of force to operate.

Compliance & Accessibility
The KB301 meets ADA and ASTM requirements when properly installed, making it suitable for a wide range of commercial applications. EN-compliant models are also available.

Colors

Beige 00

Grey 01

Black 02

White Granite 05

Product Features & Specifications

Commercial-Grade Construction: Durable, non-porous polypropylene construction is designed to withstand the demands of everyday commercial use while providing a smooth, easy-to-clean surface.
Space-Efficient Design: Vertical configuration helps maximize available wall space, making it an excellent choice for compact commercial restrooms.
Contemporary Color Options: Available in Beige, Black, Gray, and White Granite to complement a wide range of commercial restroom designs.
Heavy-Duty Internal Frame: Concealed one-piece steel chassis provides exceptional strength and rigidity in demanding commercial environments.
High Load Capacity: Supports children up to 50 lbs. (22.7 kg), exceeds ASTM F2285 requirements, and has been tested to 150 lbs. (68 kg.) with minimal deflection.
Integrated Hygiene System: Two built-in dispensers provide convenient access to sanitary bed liners and Koala Diaper Pouch® diaper disposal bags for a cleaner restroom experience.
Smooth, Controlled Operation: Concealed gas shock provides slow, controlled opening and closing, while requiring less than 5 lbs. of force.
5-year limited warranty.
Code Compliant: Meets ADA and ASTM standards; EN complaint version available.
Designed and Assembled in the USA.
Antimicrobial Changing Surface: Microban®-infused changing surface helps inhibit the growth of odor-causing bacteria between scheduled cleanings for the life of the product.

Unit Dimensions:

Width: 20 3/4″ (527.5 mm)

Height: 35 7/8″ (911 mm)

Depth (closed): 4″ (101.6 mm)

Extension (open): 36 5/8″ (931 mm)

Product Weight: 29 lbs. (13.2 kg.)

Available Configurations:

KB301-00 Beige

KB301-01 Grey

KB301-02 Black

KB301-05 White Granite

KB301-00-EN Beige (Europe)

KB301-01-EN Grey (Europe)

KB301-02-EN Black (Europe)

KB301-05-EN White Granite (Europe)

US Patent Nos. 8365328, 8276229, D605886, D601843

Canadian Patent No. 130179

European Community 1114367-0001, 1114367-0002

Australia Patent No. 325470

China Patent No. ZL200930004164.1

Taiwan Patent No. D136662

ADA Compliance Information

KB301 Baby Changing Stations have been designed to meet the applicable provisions of the 2010 ADA Standards (ADAS) and the 2009/2017 International Code Council (ICC) A117.1 Standards when properly installed and maintained. To comply with these accessibility requirements the unit must be installed in a compliant location and height in accordance with the installation instructions.

For more information, download the Plastic Baby Changing Stations Accessibility Guide.
